General Features:

• • digital multimedia receiver with AM/FM tuner (does not play discs)

  • 6.8" capacitive touchscreen

  • Bluetooth hands-free calling and audio streaming

  • multi-color illumination

  • fits double-DIN dash openings

  • wireless remote control

  Smartphone Features:

  • Apple CarPlay compatible (requires wired connection)

  • Android Auto compatible (requires wired connection)

  • USB Mirroring for select Android phones

  • built-in iPhone/iPod control

  • playback and control of music files on compatible Android devices

  • Siri Hands Free compatible for use with iPhones

  • Google Voice compatible for use with Android phones

  Audio/video Features:

  • plays MP3, WMA, AAC, FLAC, and WAV music files

  • plays lossless FLAC audio files up to 192kHz/24-bit

  • 13-band graphic equalizer

  • 7 EQ curve presets

  • high- and low-pass filters

  Expandability:

  • compatible with SiriusXM's aftermarket satellite radio tuner (sold separately, subscription required)

  • inputs: rear USB port, rear-view camera input, rear 3.5mm A/V input

  • outputs: video output, 6-channel preamp outputs (2-volt front, rear, subwoofer)

  Other Information:

  • wired connection to parking brake required to access settings and other features on this receiver (the brake must be connected and set for video display)

  • compatible with most factory steering wheel audio controls (adapter required)

  • built-in internal amp (14 watts RMS CTA-2006/50 peak x 4 channels)

Power & Output:

• RMS Power (CTA-2006): 14 watts

• RMS Power (Manufacturer): 22 watts

• Peak Output: 50 watts

Expandability:

• AUX Input: Mini (rear)

• Audio/Video Input: Mini (rear)

• USB Input: Rear

• USB Port Power: 1.5A

• Backup Camera Input: Yes

• Second Camera Input: No

• Preamp Outputs: 6-channel

• Sub Preamp Outputs: Yes

• Switchable Rear Preamp Outputs: No

• Memory Card Slot: USB memory

Smartphone Control:

• iPhone Compatibility: 5S and newer

• CarPlay: Wired only

• Siri Control: CarPlay only

• Android Control: Yes

• Android Auto: Wired only

• Alexa Voice Control: No

Tuner:

• FM Sensitivity: 13 dBf

• European Tuning: No

• Seek/Scan: Seek

• Radio Data System: Yes

File Playback:

• Music File Playback: MP3, WMA, AAC, FLAC, WAV

• High-res Playback: FLAC (192kHz)

Navigation Control:

• Navigation: CarPlay, Android Auto

• Navigation App Compatible (iOS): Apple, Google, Waze

• Navigation App Compatible (Android): Google, Waze

Features & Specs:

• Bluetooth Compatible: Built-in

• Bluetooth Version: 5.0

• Satellite Radio Ready: SiriusXM

• HD Radio: No

• Video Screen: Yes

• Preamp Voltage: 2

• Screen Size: 6.75 inches

• Screen Type: Swipeable (Capacitive)

• Display Color: N/A

• Key Button Color: Variable

• EQ Bands: 13

• Wireless Remote: Yes

• Steering Wheel Control Compatible: Adapter required

Dimensions:

• Chassis Depth: 6.515 inches

• Chassis Width: 7.015 inches

• Chassis Height: 3.955 inches

• Digital multimedia receiver(10A fuse)

• Wiring harness

• Remote control (CXE5116)

• CR2025 3V lithium battery (installed in remote)

• AV/Preout harness

• Aux-in harness

• Camera/SWC harness

• SiriusXM harness

• 58" USB extension cable

• Microphone w/ bracket (attached 13' cable terminated by a right-angled 2.5mm connector)

• Two-sided tape

• 6 Pan-head ISO screws (M5 x 9mm)

• 6 Counter-sunk ISO screws (M5 x 9mm)

• Installation Manual

• Quick Start Guide

• Warranty Sheet
